Service Guide 3-57
8719ET/20ET/22ET Adjustments and Correction Constants
8719ES/20ES/22ES Raw Offset Correction Constants
RF Network Analyzers
17.Press the following:
Note the PEEK value displayed under the PEEK label.
18.Calculate the new value by adding the PEEK value to ∆ multiplied by 4.
new value = current value + (∆ X 4)
NOTE Round the new value to the nearest integer.
19.Press and enter the new value into the poke address; press .
20.To get the analyzer to use the new poke value, press .
21.Press the following:
and enter the frequency from step 13.
The maximum marker reading is MMR.
22.Recalculate ∆ by taking the test port power (TPP), adding 4 and then subtracting the
maximum marker reading (MMR).
∆ = (TPP + 4) − (MMR)
If the magnitude of ∆ is less than 0.15 dB, then the offset for the A channel is correctly
set. Go to “Sampler Calibration Correction Constants (Test 51)” on page 3-58. If the
magnitude is greater than 0.15 dB, repeat steps 12 through 22 until the B channel raw
offset correction constant is achieved.
In Case of Difficulty
• Ensure that the power meter and power sensor are operating to specification.
• If you are unable to perform this adjustment, refer to Chapter 8 , “Receiver
Troubleshooting,” or contact the nearest Agilent Technologies sales or service office.
System
1619001374 x1
Poke x1
Preset
Meas
System
x1
To Next Page
