Agilent Technologies 8720E Series Service Guide

Service Guide 1-3
8719ET/20ET/22ET Service Equipment and Analyzer Options
8719ES/20ES/22ES Service Test Equipment
RF Network Analyzers
Service Test Equipment
Required Equipment
Critical Specifications Recommended Model or
HP/Agilent Part Number
Use
Test Instruments
Frequency Counter Freq: 0.050 to 20 GHz
Accuracy: 3ppm max
5350B, 53150A P,A,T
Frequency Counter Freq: 0.050 to 26.5 GHz
Accuracy: 3ppm max
5351B, 53151A P,A,T
Spectrum Analyzer Max Freq: 1.8 GHz RBW: 300 Hz 8591E A,T
Power Meter Accuracy: ±0.02 dB 436A, 437B, 438A
E4418A (EPM-441A)
E4419A (EPM-442A)
P, A, T
Power Sensor Freq: 0.050 to 20.05 GHz
Range: –30 to +20 dBm
8485A P,A,T
Power Sensor Freq: 0.050 to 40 GHz
Range: –30 to +20 dBm
8487A P,A,T
Digital Voltmeter Resolution: 10 mV Any T
Oscilloscope Bandwidth: 100 MHz Any T
Printer Raster graphics capability Any P
Calibration and Verification Kits
2.4 mm Calibration Kit No substitute 85056A P,A,T
2.4 mm Verification Kit No substitute 85057B P
3.5 mm Calibration Kit No substitute 85052B P,A,T
3.5 mm Verification Kit
1
1. Verification can only be done up to 26.5 GHz on the Agilent 8722ET/ES while using the 3.5
mm Verification Kit.
No substitute 85053B P
7 mm Calibration Kit No substitute 85050B P,T
7 mm Verification Kit
2
2. Verification can only be done up to 18 GHz, while using the 7mm Verification Kit.
No substitute 85051B P
Type-N Calibration Kit No substitute 85054B P,T
Type-N Verification Kit
3
3. Verification can only be done up to 18 GHz, while using the Type-N Verification Kit.
No substitute 85055A P
P - Performance Tests A - Adjustments T - Troubleshooting
