13-80 Service Guide
Replaceable Parts 8719ET/20ET/22ET
Replaceable Part Listings 8719ES/20ES/22ES
RF Network Analyzers
Hardware, Bottom
Ref.
Desig.
Models Options HP/Agilent Part
Number
Qty Description
1 All All 0515-0430 1 Screw Smm 3.0 6 Cwpntx
2 All All 0515-0458 4 Screw Smm 3.5 8 Cwpntx
3 All All 0515-0430 2 Screw Smm 3.0 6 Pcfltx
4 All All 0515-2086 6 Screw Smm 4.0 7 Pcfltx
5 All All 0515-1400 4 Screw Smm 3.5 8 Pcfltx
6 All All 0515-0433 4 Screw Smm 4.0 8 Cwpntx
6 All All 3050-0001 4 Washer Fl .172id 8
7 All All 0515-0375 4 Screw Smm 3.0 6 Cwpntx
8 All All 0515-0430 4 Screw Smm 3.0 6 Cwpntx
9 All All 0515-1400 1 Screw Smm 3.5 8 Pcfltx
10 All All 2200-0105 2 Screw Sm 440 .312 Pcfltx
11 All All 0515-0375 4 Screw Smm 3.0 16 Cwpntx
12 All All 0515-0375 2 Screw Smm 3.0 16 Cwpntx
13 All All 0515-0666 2 Screw Smm 3.0 18 Cwpntx
14 All All 0515-0665 3 Screw Smm 3.0 14 Cwpntx
15 All All 0515-0430 2 Screw Smm 3.0 6 Cwpntx
16 All All 08722-00016 2 Switch Bracket
17 All All 0515-2194 1 Screw Smm 3.0 50 Cwpntx
18 All All 0535-0031 1 Nut Hex Smm 3.0
19 All All 08720-00113 1 Bracket, Attenuator
