Agilent Technologies 8720E Series Service Guide

13-74 Service Guide
Replaceable Parts 8719ET/20ET/22ET
Replaceable Part Listings 8719ES/20ES/22ES
RF Network Analyzers
Rear Panel Assembly
Ref.
Desig.
Models Options
HP/Agilent Part
Number
Qty Description
1 All All 8120-6407 1 W85-A17 to A16
2 All All 85047-60005 2 Assy-fuse
3ET
Models
All 08753-60255 1 Bd Assy-rear Panel Interface (A16)
3ES
Models
All 08720-60138 1 Bd Assy-rear Panel Interface (A16)
4 All All 08753-60026 1 Assy-external Reference Cable
5 All All 08415-60036 1 Assy-fan
6 All All 1251-2942 4 Fastener Conn RP Lock
7 All All 2190-0034 2 Washer Lk.194ID10
7 All All 0380-0644 2 Nut Stdf .327L 6-32
8 All All 1251-2942 4 Fastener Conn RP Lock
9 All All 0515-2040 4 Screw SMM 3.5 16 PCFLTX
10 All All 0515-0372 10 Screw SMM 3.0 8 CWPNTX
11 All All 08720-00071 1 Rear Panel
12 All All 3160-0281 1 Fan Guard
15 All All 2190-0102 1 washer LK.472ID
15 All All 2950-0035 8 Nut Hex 15/32-32
16 All All 0400-0271 8 Grommet SN.5-515ID
17 All All 2110-0047 2 Fuse
17 All All 1400-0112 2 Fuse Cap
