Agilent Technologies 8720E Series Service Guide

1-4 Service Guide
Service Equipment and Analyzer Options 8719ET/20ET/22ET
Service Test Equipment 8719ES/20ES/22ES
RF Network Analyzers
Required Equipment Critical Specifications Recommended Model or
HP/Agilent Part Number
Use
Adapters and Loads
RF Load 3.5 mm(f), 50 ohm 00902-60004
(Part of 85052B)
P
RF Load 2.4 mm(f), 50 ohm 00901-60004
(Part of 85056A)
P
RF Short 3.5 mm (f) 85052-60007
(Part of 85052B)
P
RF Short 2.4mm (f) 85056-60021
(Part of 85056A)
P
RF Open 3.5 mm(f) 85052-60009
(Part of 85052B)
A
RF Open 2.4 mm(f) 85056-60023
(Part of 85056A)
A
RF Adapter 3.5 mm(f) to 3.5 mm(f) 85052-60012
(Part of 85052B)
P, A
RF Adapter 2.4 mm(f) to 2.4 mm(f) 85056-60006
(Part of 85056A)
P, A
RF Power Splitter 3.5 mm 11667B T
RF Power Splitter 2.4 mm 11667C T
RF Fixed Attenuator 3.5 mm 8493C Opt. 010 A
RF Fixed Attenuator 2.4 mm 8490D Opt. 010 A
RF Adapter 2.4 mm (f) to Type-N (f) 11903B A
RF Adapter 3.5 mm (f) to Type-N (f) 1250-1745 (2 total) A
Cables
RF Cable BNC 50 ohm, 24 inch 8120-2582 A
RF Cable Type-N (m) connectors, 50W,
24-inch
11500C (2 total) P,A
RF Cable Set 3.5 mm connectors 85131F P,A,T
RF Cable Set 7 mm connectors to 3.5 mm 85132F P
RF Cable Set 2.4 mm connectors 85133F P,A,T
Extension Cables SMB (f) to BNC (m) (4 ft. length) 8120–5048 T
Extension Cables SMB (m) to SMB (f) 8120–5040 A,T
Coax Cable BNC (m) to BNC (m), 50W 10503A A
GPIB Cables 1 meter length 10833A A
P - Performance Tests A - Adjustments T - Troubleshooting
