Service Guide 10-35
8719ET/20ET/22ET Service Key Menus and Error Messages
8719ES/20ES/22ES Service Related Error Messages in Alphabetical Order
RF Network Analyzers
CURRENT PARAMETER NOT IN CAL SET
Error Number
64
Correction is not valid for your selected measurement parameter. Either change
the measurement parameters or perform a new calibration.
DEADLOCK
Error Number
111
A fatal firmware error occurred before instrument preset completed. Call your
nearest Agilent Technologies sales or service office.
DEVICE: not on, not connect, wrong addrs
Error Number
119
The device at the selected address cannot be accessed by the analyzer. Verify
that the device is switched on, and check the GPIB connection between the
analyzer and the device. Ensure that the device address recognized by the
analyzer matches the GPIB address set on the device itself.
DISK HARDWARE PROBLEM
Error Number
39
The disk drive is not responding correctly. If using an external disk drive, refer
to the disk drive operating manual.
DISK MESSAGE LENGTH ERROR
Error Number
190
The analyzer and the external disk drive aren’t communicating properly. Check
the GPIB connection and then try substituting another disk drive to isolate the
problem instrument.
DISK: not on, not connected, wrong addrs
Error Number
38
The disk cannot be accessed by the analyzer. Verify power to the disk drive, and
check the GPIB connection between the analyzer and the disk drive. Ensure
that the disk drive address recognized by the analyzer matches the GPIB
address set on the disk drive itself.
DISK READ/WRITE ERROR
Error Number
189
There may be a problem with your disk. Try a new floppy disk. If a new floppy
disk does not eliminate the error, suspect hardware problems.
FILE NOT COMPATIBLE WITH INSTRUMENT
Information
Message
You cannot recall user graphics that had been saved on an earlier model of
analyzer with a monochrome display.
ILLEGAL UNIT OR VOLUME NUMBER
Error Number
46
The disk unit or volume number set in the analyzer is not valid. Refer to the
disk drive operating manual.
