13-36 Service Guide
Replaceable Parts 8719ET/20ET/22ET
Replaceable Part Listings 8719ES/20ES/22ES
RF Network Analyzers
Bottom Assemblies and Cables for 8722ES Options 007+012
Ref. Desig. Options HP/Agilent
Part Number
Qty
Description
A7 08720-60253 1 CPU Repair Kit
A7 08720-69253 1 CPU Repair Kit (Rebuilt-Exchange)
A17 08720-60264 1 Motherboard
A51 08720-60274 1 Bd Assy-Test Set Interface
A52 5086-7456 1 Assy-Pulse Generator
A52 5086-6456 1 Assy-Pulse Generator (Rebuilt-Exchange)
A60,A61 5086-7484 2 Bias Tee
A60,A61 5086-6484 2 Bias Tee (Rebuilt-Exchange)
A64,A65,A66 5086-7614 3 Assy-Sampler
A64,A65,A66 5086-6614 3 Assy-Sampler (Rebuilt-Exchange)
A69 33326-60006 1 Attenuator 0-55 dB
A74
1
1. The A74 switch has 2 interconnect cables that are not shown. Part number is 08722-20010.
08722-60098 1 Transfer Switch
A98 08720-60121 1 Frequency Converter
A98 08720-69121 Frequency Converter (Rebuilt-Exchange))
W14 08722-20102 1 A63 to Front Panel B-Out
W15 08722-20079 1 Front Panel B-In to A66
W16 08722-20081 1 Front Panel A-In to A65
W17 08722-20102 1 A62 to Front Panel A-Out
W25 08722-20056 1 A61 to A62
W26 08722-20057 1 A60 to A63
W27 08722-20078 1 A74 to A60
W28 08722-20077 1 A74 to A61
W29 08722-20076 1 A69 to A74
W32 08722-20069 1 A58 to A69
W36 08720-20041 1 A72 to A64
W52 08722-20024 3 External Link
