Agilent Technologies 8720E Series Service Guide

13-50 Service Guide
Replaceable Parts 8719ET/20ET/22ET
Replaceable Part Listings 8719ES/20ES/22ES
RF Network Analyzers
Bottom Assemblies and Cables for 8722ES Option 400+012
Ref. Desig. Options HP/Agilent
Part Number
Qty
Description
A7 08720-60253 1 CPU Repair Kit
A7 08720-69253 1 CPU Repair Kit (Rebuilt-Exchange)
A17 08720-60264 1 Motherboard
A51 08720-60274 1 Bd Assy-Test Set Interface
A52 5086-7456 1 Assy-Pulse Generator
A52 5086-6456 1 Assy-Pulse Generator (Rebuilt-Exchange)
A60,A61 5086-7484 2 Bias Tee
A60,A61 5086-6484 2 Bias Tee (Rebuilt-Exchange)
A64,A65,
A66,A67
5086-7614 4 Assy-Sampler
A64,A65,
A66,A67
5086-6614 4 Assy-Sampler (Rebuilt-Exchange)
A70,A71 33326-60006 2 Attenuator 0-55 dB
A74 5087-7002 1 Switch Splitter
A74 5087-6002 1 Switch Splitter (Rebuilt-Exchange)
A99 08720-60124 1 Frequency Converter
A99 08720-69124 Frequency Converter (Rebuilt-Exchange)
W14 08722-20102 1 A63 to Front Panel B-Out
W15 08722-20079 1 Front Panel B-In to A66
W16 08722-20081 1 Front Panel A-In to A65
W17 08722-20102 1 A62 to Front Panel A-Out
W25 08722-20056 1 A61 to A62
W26 08722-20057 1 A60 to A63
W32 08722-20054 1 A58 to A74
W36 08720-20041 1 A72 to A64
W37 08722-20059 1 A71 to A60
W38 08722-20061 1 A70 to A61
W39 08722-20063 1 A74 to A70
W40 08722-20062 1 A74 to A71
W41 08722-20936 1 A74 to A76
W52 08722-20024 3 External Link
