152 Maintaining Your GC
9 Maintaining the PTV Inlet
Consumables and Parts for the PTV Inlet
See the Agilent catalog for consumables and supplies for a
more complete listing, or visit the Agilent Web site for the latest
information (www.agilent.com/chem/supplies).
Tab le 2 2 PTV liners and ferrules
Description Part number
Single baffle, 2-mm id, 180-µL, deactivated, glass wool 5183-2038
Single baffle, 2-mm id, 200-µL, deactivated 5183-2036
Multi-baffle, 1.5-mm id, 150-µL, deactivated 5183-2037
Fritted glass, 1.5-mm id, 150-µL, deactivated 5183-2041
Graphpak 3D ferrules for liner 5182-9749 (5/pk)
Installation tool for 3D ferrules G2617-80540
Tab le 2 3 Other consumables and parts for the PTV inlet
Description Part number
Syringe, 5-µL, 23-gauge fixed-needle 9301-0892
Syringe, 10-µL, 23-gauge fixed-needle 9301-0713
Syringe, 50-µL, 23-gauge fixed-needle, for large volume
injections
5183-0318
Syringe, 100-µL, 23-gauge fixed-needle, for large volume
injections
5183-2058
Split vent trap PM kit, single cartridge 5188-6495
Septumless head
Septumless head G2617-60507
PTFE ferrules (needle seal) 5182-9748 (10/pk)
Septumless head rebuild kit (includes Viton seal, Kalrez
seal, and pressure spring)
5182-9747
Carrier gas tube for septumless head G2617-80550
Ferrule, 1/16-inch PTFE, for septumless head carrier gas
tube
0100-1375
Septum head
Merlin Microseal septum (high-pressure) 5182-3444
11-mm septa, red 5181-1263 (50/pk)
