330 Maintaining Your GC

18 Maintaining the PCM

Consumables and Parts for the PCM

See the Agilent catalog for consumables and supplies for a

more complete listing, or visit the Agilent Web site for the latest

information (www.agilent.com/chem/supplies).

Tab le 5 1 PCM consumables

Description Part number

O-rings, package of 12 5180-4181

Proportional valve, Carrier G3430-67013

Proportional valve, AUX G3430-67016
