68 Maintaining Your GC
6 Maintaining the Purged Packed Inlet
Consumables and Parts for the Purged Packed Inlet
See the Agilent catalog for consumables and supplies for a
more complete listing, or visit the Agilent Web site for the latest
information (www.agilent.com/chem/supplies).
Tab le 9 Purged packed inlet parts
Description Part number/quantity
Preventative maintenance kit 5188-6498
Purged packed glass liners and column adapters
Glass liner 5080-8732 (25/pack) or
5181-3382 deactivated
(5/pack)
0.53-mm column adapter 19244-80540
1/8-inch column adapter 19243-80530
1/4-inch column adapter 19243-80540
Recommended septa and O-rings for the purged packed inlet
11-mm solid septum, low-bleed, red 5181-1263 (50/pk)
11-mm septum with partial through-hole,
low-bleed, red
5181-3383 (50/pk)
11-mm septum, low-bleed, gray 5080-8896 (50/pk)
Merlin Microseal septum (30 psi) 5181-8815
11-mm high-temperature silicone septum
(350 °C and higher)
5182-0739 (50/pk)
Viton O-ring (Top insert weldment) 5080-8898 (12/pk)
Tab le 1 0 Nuts and ferrules for packed columns
Description Typical use Part number/quantity
1/8-inch id Swagelok
stainless steel nut, front
ferrule, back ferrule
1/8-inch column 5080-8751 (20 each/pk)
1/8-inch id Swagelok
brass nut, front ferrule,
back ferrule
1/8-inch column 5080-8750 (20 each/pk)
1/8-inch id Vespel/
graphite ferrule
1/8-inch column 0100-1332 (10/pk)
