246 Maintaining Your GC

13 Maintaining the uECD

Exploded Parts View of the uECD

Vent line

Warning tag

Perforated cover

Electrometer

Ferrule

Adapter nut

Cap

Liner

Makeup gas adapter

Insulation

Insulation cup

Ferrule

Column nut
