Maintaining the NPD 14
Maintaining Your GC 261
Tab le 4 0 Jets for capillary optimized fittings
Jet type Part number Jet tip id Length
Capillary with extended jet
(recommended)
G1534-80580 0.29 mm
(0.011 inch)
51.5 mm
Capillary G1531-80560 0.29 mm
(0.011 inch)
43 mm
High-temperature G1531-80620 0.47 mm
(0.018 inch)
43 mm
Tab le 4 1 Jets for adaptable fittings
Jet type Part number Jet tip id Length
Capillary with extended jet
(recommended)
G1534-80590 0.29 mm
(0.11 inch)
70.5 mm
Capillary 19244-80560 0.29 mm
(0.011 inch)
61.5 mm
Capillary, high-temperature 19244-80620 0.47 mm
(0.018 inch)
61.5 mm
Packed 18710-20119 0.46 mm
(0.018 inch)
63.6 mm
Tab le 4 2 Nuts, ferrules, and hardware for capillary columns
Column id (mm) Description Typical use Part number/quantity
.530 Ferrule, Vespel/graphite,
0.8-mm id
0.45-mm and 0.53-mm capillary
columns
5062-3512 (10/pk)
Ferrule, graphite, 1.0-mm id 0.53-mm capillary columns 5080-8773 (10/pk)
Ferrule, graphite, 0.8-mm id 0.53-mm capillary columns 500-2118 (10/pk)
Column nut, finger-tight (for
0.53-mm columns)
Connect column to inlet or detector 5020-8293
.320 Ferrule, Vespel/graphite,
0.5-mm id
0.32-mm capillary columns 5062-3514 (10/pk)
Ferrule, graphite, 0.5-mm id 0.1-mm, 0.2-mm, 0.25-mm, and
0.32-mm capillary columns
5080-8853 (10/pk)
Column nut, finger-tight (for
.100- to .320-mm columns)
Connect column to inlet or detector 5020-8292
