Maintaining a Valve 19

Maintaining Your GC 339

Install the new sample loop.

11 Repressurize the sample loop and check for leaks.

12 Install the upper valve box. (See “To Install the Upper

Valve Box” on page 346.)

13 Restore the analytical method.
