Navigating through the information
-1- Scroll through the decode using the arrow keys.
At the top right of the screen, aurora
Sonata
shows
the time at which the currently highlighted
event occurred.
-2- When you have finished viewing the real time
buffer contents, press ESC to return to the list
of sessions available for viewing.
Sending the decode to the serial port
As well as viewing a simple protocol decode displayed on-
screen, you can send a more detailed decode to aurora
Sonata
’s
serial port for output to a printer or PC.
Note
You can also output protocol information which has been
previously stored in aurora
Sonata
’s memory. For details, see
Sending the capture session to a printer or PC in section 2.
Choosing the format for the decode
There are various formats available for decode output to the
serial port, allowing data to be analysed in different ways:
troPlaireSehttatuptuOlocotorP
edoceD 3reyaLdna2reyaL,1reyaLfoedocedlaitrapA
Dehtfopmudlamicedaxehllufhtiwgnillangis
,rotacidnievieceR/timsna
rThtiwsegassemlennahc
emit.ecnereferemarfdnapmats
trepxE aroruadnalocotorpNDSIehtfotuptuollufA
atanoS
gnisudesylanaebnachcihwtamrofani,noitarepo
aroruadnerT
trepxE
.swodniWrof
gubeD tahtsegassemehtgniwohs,edocedlocotorpISOnA
,kcatslocotorpehtnireyalhcaeneewtebtnesera
dnadettimsnartgni
ebsegassemlennahCDsulp
.2reyaLybdeviecer
You choose a format using the Tracer setting in the Comms/
Tracer menu (see Configuring the serial port/protocol output
in Chapter 3 section 1). When you connect to a PC or printer
and begin a call or monitor session, aurora
Sonata
begins sending
decode in the selected format.
