aurora
Sonata
Hand Held ISDN Tester—User Guide
2-18 427869
Selecting an interface
aurora
Sonata
can be fitted with Basic Rate interface modules
allowing you to test at the S or U interface.
The Primary Rate interface module allows you to test Primary
Rate links using E1 type access.
Note
You cannot select a new interface while a call is connected.
-1-
With the Interfaces window active in the top
level menu, highlight the interface you require:
Note
The Interfaces window lists the interfaces that are fitted on
your aurora
Sonata
. Where you have two interfaces which can be
combined to perform a specific task (e.g. two 4B3T U
interfaces) you have the option to select both of them.
-2-
Press ENTER. A tick (9) appears next to the
the selected interface. The LED on the
interface module will also light up when you
go into the Simulate or Monitor menu.
The Main Menu automatically changes to suit the tests that
you can perform with the selected interface or interfaces. For
example, when you choose an interface that is only used in
Simulation mode, the Monitor option is removed.
-3-
Switch back to the Main Menu window to
begin.
