Issue 2 - 07/00 7-25
Capturing & Analysing Protocol Information - Section 3
Replied with an ,
Frames received 2.
Received the message,
Frames received 1,
Frames sent 2.
Transmit
message.
RR
CONNECT
CONNECT ACKNOWLEDGE
Decode Output Explanation
TX 09:42:37:898 Frame 4
L2: RR
Sapi=0 Tei=0
Pf=0 Nr=2 02 01 01 04
RX 09:42:44:773 Frame 4
L2: Info
Sapi=0 Tei=0
Pf=0 Nr=1 Ns=2
L3: CONNECT
Pd=8 Cr(D)=1
I4C Connected numb
Numb=123452
02 01 04 02 08 01 81 07 4C 08
21 80 31 32 33 34 35 32
TX 09:42:44:776 Frame 5
L2: RR
Sapi=0 Tei=0
Pf=0 Nr=3
02 01 01 06
TX 09:42:44:787 Frame 6
L2: Info
Sapi=0 Tei=0
Pf=0 Nr=3 Ns=1
L3: CONNECT ACK
Pd=8 Cr(O)=1
00 01 02 06 08 01 01 0F
02 01 06 04
