108 1100 Series WS MWS Reference Manual
4 Repairing the Sampler
Overview of Main Repair Procedures
Figure 18 Main Assemblies
Peristaltic
pump
Injection
valve
Analytical
head
Needle
Transport
assembly
MTP board
Power supply
Needle seat
SLS
board
Loop
capillary
Needle carrier
