Electrical Connections
WARNING
Never use cables other than the ones supplied by Agilent Technologies to ensure
proper functionality and compliance with safety or EMC regulations.
Figure 36 Well-plate Sampler Electrical Connections
DC-Out
RS232C
CAN-bus
Remote
Vial number output
Relay
contacts
CAN cable to next module
CAN cable to previous module
Control of Thermostat
WARNING
DO NOT disconnect or reconnect the autosampler to ALS thermostat cable when the
power cords are connected to either of the two modules. This will damage the
electronics of the modules.
