Optional Interface Boards
The Agilent 1100 Series modules have one optional board slot that allows
addition of an interface board to the modules.
BCD Board
The BCD board provides a BCD output for the bottle number of the
Agilent 1100 Series well-plate sampler and four external contacts. The
external contact closure contacts are relay contacts. The maximum settings
are: 30 V (AC/DC); 250 mA (fused). There is a general purpose cable available
to connect the BCD output, see “BCD Cables" on page 188 and the external
outputs, see “External Contact Cable" on page 193 to external devices.
Tabl e 63 Optional Interface Boards
Description Part Number
BCD Board G1351-68701
Fuse 250 mA (four are on the board) 2110-0004
LAN Board (see next page for details)
To Next Page
