242 1100 Series WS MWS Reference Manual
8 Control Module Screens of the Well-plate Samplers
Major keys on the Agilent 1100 Control Module
Tabl e 78
ESC Return to previous screen, abort any change of parameters and toggle between
the last two top layer views
m Open context sensitive menus
i Information/Help
Enter Store changed parameters or execute a choice
Done (If available) Activate settings of current screen
On/Off Switch on individual Instrument(s) or complete System
Start Start a location range or sequence
Plot View online signals
Views Change between analysis - (samples)- status - system views
NOTE
The screens shown on the next pages are based on:
Control Module firmware revision B.02.0x (G1323B)
HPLC Module firmware revision 4.08
NOTE
In case the control module’s display seems to be frozen (hang-up due to a communication
problem on the CAN bus), unplug the control module from the HPLC module and reconnect.
