Agilent Technologies G1377A User Manual

188 1100 Series WS MWS Reference Manual
5 Parts and Materials
BCD Cables
One end of these cables provides a 15-pin BCD connector to be connected to
the Agilent 1100 Series modules. The other end depends on the instrument to
be connected to.
NOTE
The BCD output for the well plate sampler does not work with the integrators 3392/3/6.
Tabl e 49 Agilent 1100 to 3392/3 Integrators
Connector
18584-60510
Pin
3392/3
Pin
Agilent 1100
Signal Name BCD Digit
10 1 BCD 5 20
11 2 BCD 7 80
33BCD 640
94BCD 410
7 5 BCD 0\ 1
56BCD 38
12 7 BCD 2 4
48BCD 12
1 9 Digital ground
215+5VLow
6 - Key
