228 1100 Series WS MWS Reference Manual
7 Theory of Operation
Interfaces
The Agilent 1100 Series modules provide the following interfaces:
• CAN connectors as interface to other Agilent 1100 Series modules,
• GPIB connector as interface to the Agilent ChemStation,
• RS-232C as interface to a computer,
• REMOTE connector as interface to other Agilent products,
• Analog Output connector(s) for signal output, and
• Interface slot for specific interfacing (external contacts, BCD, LAN and so
on).
For identification and location of the connectors Figure 5 on page 25.
Tabl e 65 Agilent 1100 Series Interfaces
Interface Type Pumps Autosampler Well-plate
Sampler
DA Detector
MW
Detector
FL Detector
VW Detector
RI Detector
Thermostatted
Column
Compartment
Vacuum
Degasse
r
CAN YesYesYesYesYesYes No
GPIB Yes Yes No
*
Yes Yes Yes No
RS-232CYesYesYesYesYesYes No
R em ot e Yes Ye s Ye s Ye s Ye s Ye s Ye s
AnalogYesNoNo2×1×No Yes
†
Interface
board
Ye s Ye s Ye s Ye s Ye s No N o
* The well-plate sampler can be controlled through CAN via a detector that is connected via GPIB to a ChemStation.
† The vacuum degasser will have a special connector for specific use. For details see description of main board.
WARNING
Never use cables other than the ones supplied by Agilent Technologies to ensure
proper functionality and compliance with safety or EMC regulations.
