Parts and Materials 5
1100 Series WS MWS Reference Manual 159
Tabl e 19 Well-plate Sampler Main Assemblies
Item Description Part Number
1 Ribbon Cable (from SU to MTP) G1313-81602
2 Sample Transport assembly for G1367A
Sample Transport assembly for G1377A
G1367-60019
G1377-60009
3 Sampling Unit assembly for G1367/68A
Sampling Unit assembly for G1377/78A
(The assy comes without injection valve and analytical head)
G1367-60008
G1377-60008
4 SLS board (not shown) G1367-66505
5 Analytical Head assembly (100 µl) for G1367/68A
Analytical Head assembly (40 µl) for G1377/78A
G1367-60003
G1377-60013
6 Injection Valve assembly for G1367/68A
Micro Injection valve assembly for G1377/78A
0101-0921
0101-1050
7 Needle Seat assy for G1367/68A
Needle Seat assy for G1377/78A (without capillary)
Seat cap. (0.10 mm ID 1.2 µl) for G1377-87101 Needle Seat
Seat cap. (0.05 mm ID 0.3 µl) for G1377-87101 Needle Seat
G1367-87101
G1377-87101
G1375-87317
G1375-87300
8 Plate Tray G1367-60001
9Needle assy for G1367/68A
Needle assy for G1377/78A
G1367-87201
G1377-87201
10 Needle Carrier assembly G1367-60010
11 Power supply assembly (not visible) 0950-2528
12 Well-Plate Sampler Main Board (MTP)
Exchange Assembly - MTP board
G1367-66500
G1367-69500
13 Ribbon Cable (from ST to MTP) G1364-81601
Ribbon Cable (from SLS to MTP) (not visible) G1367-81600
Sampler-TCC cap. (380 mm, 0.17 mm id) for G1367/68A
Sampler-TCC cap. (500 mm, 0.05 mm id) for G1377/78A
01090-87306
G1375-87304
Fan (not visible) 3160-1017
Fan exhaust (not visible) 3160-4097
BCD board (not visible) G1351-68701
