128 34410A/11A/L4411A User’s Guide
5 Specifications
AC Characteristics
Accuracy Specifications ±( % of reading + % of range )
[1]
[ 1 ] Specifications are for 90 minute warm–up, slow ac filter, sinewave.
[ 2 ] Relative to calibration standards.
[ 3 ] 20% overrange on all ranges, except 750 Vac, 3 A range.
[ 4 ] Specifications are for sinewave input >0.3% of range and > 1mVrms.
Add 30 µV error to AC voltage specification for frequencies < 1kHz.
750 VAC range limited to 8 x 10
7
Volt–Hz.
750 VAC range add 0.7 mV of error for each additional volt over 300 VAC.
[ 5 ] Specifications are for sinewave input >1% of range and > 10 µArms.
Frequencies > 5 kHz are typical for all ranges.
For the 3 A range (all frequencies), add 0.05% of reading + 0.02% of range to listed specifications.
Low Frequency Performance
Three filter settings are available: 3 Hz, 20 Hz, 200Hz.
Frequencies greater than these filter settings are specified with no additional errors.
AC Current Burden Voltage
Function Range
[3]
Frequency Range 24 Hour
[2]
T
CAL
± 1 °C
90 Day
T
CAL
± 5 °C
1 Year
T
CAL
± 5 °C
Temperature
Coefficient/°C
0 °C
to (T
CAL
– 5 °C)
(T
CAL
+ 5 °C) to 55 °C
True RMS A C
Voltage
[4]
100.0000 mV
to
750.000 V
3 Hz – 5 Hz
5 Hz – 10 Hz
10 Hz – 20 kHz
20 kHz – 50 kHz
50 kHz – 100 kHz
100 kHz – 300 kHz
0.50 + 0.02
0.10 + 0.02
0.02 + 0.02
0.05 + 0.04
0.20 + 0.08
1.00 + 0.50
0.50 + 0.03
0.10 + 0.03
0.05 + 0.03
0.09 + 0.05
0.30 + 0.08
1.20 + 0.50
0.50 + 0.03
0.10 + 0.03
0.06 + 0.03
0.10 + 0.05
0.40 + 0.08
1.20 + 0.50
0.010 + 0.003
0.008 + 0.003
0.005 + 0.003
0.010 + 0.005
0.020 + 0.008
0.120 + 0.020
True RMS A C
Current
[5]
100.0000µA
to 3.00000A
3 Hz – 5 kHz
5 kHz – 10 kHz
0.10 + 0.04
0.20 + 0.04
0.10 + 0.04
0.20 + 0.04
0.10 + 0.04
0.20 + 0.04
0.015 + 0.006
0.030 + 0.006
ACI Ranges Voltage
100.0000 µA
1.000000 mA
10.00000 mA
100.0000 mA
1.000000 A
3.00000 A
<0.03 V
<0.3 V
<0.03 V
<0.3 V
<0.8 V
<2.0 V
