42 34410A/11A/L4411A User’s Guide
2Features and Functions
Front–Panel Display Shortcuts
Direct front–panel shortcuts are provided for three commonly used display
functions: ranging, digit masking, and integration time. These shortcuts are
available only when you are not in a menu.
Ranging. The meter range can be set directly from the navigation keypad.
• To manually change the range, press or . The
ManRng annunciator
lights, and the selected range (for example, 100mV RANGE) is briefly displayed
on the second line.
• To toggle between the selected manual range and autoranging, press
. The ManRng annunciator toggles on or off, as appropriate.
Note: This is a dual–function key, not a shifted key. Pressing when in
a menu will exit the menu.
Digit Masking. The navigation keypad provides a shortcut to mask (change
the number of digits displayed) the reading on the main display.
• To enable digit masking for the selected measurement function, press
or . DIGIT MASK will be displayed, along with a list of choices
(3.5, 4.5, 5.5, 6.5 and AUTO). Select the desired setting (use the keys)
and press .
• Masking digits only affects what is displayed. It does not affect
measurement speed or accuracy.
Integration Time (Bandwidth, Gate Time). Four measurement functions allow
you to select the integration time: dc voltage, dc current, resistance, and
temperature. The ac voltage and ac current measurements allow you to select
the ac signal filter (bandwidth). The frequency/period function allows you to
select gate time. The navigation keypad provides a shortcut for quickly
changing these settings.
• If the multimeter is configured to take the measurement using an
integration time in NPLCs, press or to increase or decrease the
integration time setting and display the new setting briefly. You can scroll
through the entire range of integration time settings:
Agilent 34410A, PLCs: 0.006, 0.02, 0.06, 0.2, 1, 2, 10 and 100
Agilent 34411A/L4411A, PLCs: 0.001, 0.002, 0.006, 0.02, 0.06, 0.2, 1, 2, 10, 100
UG_ED5.book Page 42 Thursday, March 1, 2012 11:28 AM
