136 34410A/11A/L4411A User’s Guide
5 Specifications
Data From Memory
Maximum reading rate out of memory
(Sample count 50000, trigger count 1, "FETC?" or "R?")
General Specifications (34410A/11A)
Power Supply: 100V/120V/ 220V / 240V ± 10%
Power Line Frequency: 50–60 Hz ± 10%,
400 Hz ± 10%.
Automatically sensed at power–on, 400 Hz defaults to 50Hz.
Power Consumption: 25 VA peak ( 16 W average )
Operating Environment: Full accuracy for 0 °C to 55 °C
Full accuracy to 80% R.H. at 40
o
C Non–condensing
Storage Temperature: –40 °C to 70 °C
Operating Altitude: Up to 3000m
Rack Dimensions (WxHxD)
: 212.8mm x 88.3mm x 272.3mm
Bench Dimensions (WxHxD)
: 261.2mm x 103.8mm x 303.2mm
Weight: 3.72 kg (8.2 lbs)
Safety: IEC 61010-1
EN 61010-1
UL 61010-1
CAN/CSA-C22.2 No. 61010-1
Refer to Declaration of Conformity for current revisions.
Measurement CAT II 300V, CAT I 1000V
Pollution Degree 2
EMC: IEC 61326, EN 61326, CISPR 11, ICES-001, AS/NZS 2064.1
Refer to Declaration of Conformity for current revisions.
Acoustic Noise: 37 dBa
Display: Dual–line, 17–segment vacuum florescent display
State Storage Memory: Power Off state automatically saved, 4 User Configurable Stored States
Remote Interfaces: GPIB IEEE–488, 10/100Mbit LAN, USB 2.0 Standard
Language: SCPI – 1994.0, IEEE–488.2
LXI Compliance: LXI Class C, Version 1.0
Warm–up Time: 90 minutes
Readings GPIB
rdg/Sec
USB 2.0
rdg/Sec
LAN (VXI-11)
rgs/Sec
LAN (Sockets)
rdg/Sec
ASCII 4000 8500 7000 8500
4–byte Binary 89,000 265,000 110,000 270,000
8–byte Binary 47,000 154,000 60,000 160,000
UG_ED5.book Page 136 Thursday, March 1, 2012 11:28 AM
