34410A/11A/L4411A User’s Guide 89
Remote Interface Configuration 3
Configuring the GPIB Interface
Each device on the GPIB (IEEE–488) interface must have a unique address.
You can set the multimeter’s address to any integral value between 0 and 30.
The address is set to “22” when the instrument is shipped from the factory.
• Your computer’s GPIB interface card has its own address. Be sure to avoid
using that address for any instrument on the interface bus.
• The GPIB address is stored in non–volatile memory, and does not change
when power has been off, after a Factory Reset (*RST) command, or after
an Instrument Preset (SYSTem:PRESet) command.
• Front Panel Operation: Press
UTILITY MENU > REMOTE I/O > GPIB > ENABLE GPIB? > GPIB ADDRESS
After enabling or disabling GPIB, you must cycle the power for the change
to take effect.
•
Remote Interface Operation: The following command enables the GPIB
remote interface:
SYSTem:COMMunicate:ENABle ON,GPIB
The following command queries the state of the GPIB interface:
SYSTem:COMMunicate:ENABle? GPIB
This query returns a “0” (OFF) or a “1” (ON).
The following command sets the multimeter’s GPIB (IEEE–488) address:
SYSTem:COMMunicate:GPIB:ADDRess {<
address
>}
The following query returns the IP address, (for example “+22”):
SYSTem:COMMunicate:GPIB:ADDRess?
Refer to the Agilent 34410A/11A/L4411A Programmer’s Reference Help for
complete description and syntax for these commands.
UG_ED5.book Page 89 Thursday, March 1, 2012 11:28 AM
