34410A/11A/L4411A User’s Guide 137
Specifications 5
General Specifications (L4411A)
Power supply: Universal 100V to 240V ±10%
Power line frequency: 45 Hz to 440 Hz +/- 10% automatically sensed
Power consumption: 50 VA peak (18W average)
Operating Environment: Full accuracy for 0 °C to 55 °C
Full accuracy to 80% R.H. at 40 °C
Storage environment: -40 °C to 70 °C
Dimensions (H x W x L): 40.9 x 212.3 x 363.2 mm
1.61 x 8.36 x 14.3 in
Weight: 1.9 kg, 4.25 lbs
Display: Dual–line, 5x7 Dot Matrix, 16-character LCD
Safety: conforms to CSA, UL/IEC/EN 61010-1
EMC: conforms to IEC/EN 613226-1, CISPR 11
Warranty: 1 year
Triggering and Memory
Reading Hold Sensitivity: 1% of reading
Samples per Trigger: 1 to 50,000 (34410A)
1 to 1,000,000 (34411A/L4411A)
Trigger Delay: 0 to 3600 sec (20 μs step size)
External Trigger Low–power TTL compatible input programmable edge triggered
Delay: < 1μs
Jitter: < 1μs
Max rate up to 5 kHz
Min Pulsewidth 1 μs
Voltmeter Complete 3 V Logic output
Polarity Programmable edge pulse
Pulsewidth Approximately 2 μs
Non–volatile Memory 50,000 readings
Sample Timer
Range Up to 3600 sec in 20 μs steps
Jitter < 100 ns
