34410A/11A/L4411A User’s Guide 15
Quick Start 1
Using the Front Panel (34410A/11A)
This section introduces the 34410A/11A multimeter front panel.
Front-Panel Keys
The front panel provides keys to select various functions and operations.
Pressing a measurement function key (e.g. ) selects that function. Press
to enter the configuration menu for the selected measurement function.
Most keys have a shifted function printed in blue above the key. To perform a
shifted function, press , and then press the key that has the desired label
above it.
To view and select menu items, use the menu navigation keypad (for example
the or keys). The current (or default) selection is displayed in FULL
BRIGHTNESS. All other choices are displayed in HALF BRIGHTNESS. The selections
on each menu level scroll, but do not wrap. Arrow annunciators on the second
display line indicate additional selections to the left or right. To accept a
selection, press .
To set numeric parameters, use or to select a digit, and or to
increase or decrease that digit.
