Features and Functions 2
Second Display Options
Many measurement functions allow a secondary measurement to be displayed
simultaneously on the second display line:
• Front Panel Operation: Press
2ND DISPLAY > PK-TO-PK (Where primary function is voltage or current.)
Once the second display is enabled, you can scroll through all second
display items, including STATS or LIMITS if these functions are enabled.
• Remote Interface Operation: The following command selects the measurement
or math function to be displayed on the second display line. The <feed>
parameter is a quoted ASCII string designating the function to be displayed,
such as VOLTage:PTPeak.
DISPlay:WINDow2:TEXT:FEED <feed>
The following query returns the currently selected
<feed>
parameter, as a
quoted ASCII string:
DISPlay:WINDow2:TEXT:FEED?
Refer to the Agilent 34410A/11A/L4411A Programmer’s Reference Help for
a complete description and syntax for these commands.
Turning the Display Off
This feature is available from the remote interface only.
For security reasons, you may want to disable the front panel display. When
disabled, the entire front panel display (except for the Error and Remote
annunciators) goes dark.
• Remote Interface Operation: The following command turns off the display:
DISPlay OFF
The following command queries the display setting:
DISPlay?
The query returns a “0” (OFF) or “1” (ON).
Refer to the Agilent 34410A/11A/L4411A Programmer’s Reference Help for
a complete description and syntax for these commands.
Primary Function Second Display Function
DC V, DC I, AC V, AC I Peak–to–Peak value
Freq AC Voltage
*
Temp Raw Resistance**
*ac voltage of the input waveform
**actual raw resistance measured across temperature probe and leads
