74 34410A/11A/L4411A User’s Guide
2Features and Functions
2–wire Resistance Measurements:
4–wire Resistance Measurements
Capacitance
AC Voltage Measurements (all ranges):
AC Current Measurements (all ranges):
Frequency and Period
Range Trigger Delay
(for ≤ 0.02 PLC)
Trigger Delay
(for 0.06 or 0.2 PLC)
Trigger Delay
(for ≥ 1 PLC)
100 Ω 80 μs100 μs130 μs
1 kΩ 110 μs130 μs160 μs
10 kΩ 130 μs160 μs190 μs
100 kΩ 540 μs670 μs800 μs
1 MΩ 5.0 ms 6.0 ms 7.5 ms
10 MΩ
– 1GΩ 60 ms 70 ms 84 ms
Range Trigger Delay
(for ≤ 0.02 PLC)
Trigger Delay
(for 0.06 or 0.2 PLC)
Trigger Delay
(for ≥ 1 PLC)
100Ω
– 100 kΩ 1.0 ms 1.0 ms 1.5 ms
1 MΩ 10 ms 10 ms 15 ms
10 MΩ
– 1GΩ 100 ms 100 ms 100 ms
Trigger Delay
0 s
AC Filter Trigger Delay
Slow (3 Hz) 2.5 s
Medium (20 Hz) 625 ms
Fast (200 Hz) 25 ms
AC Filter Trigger Delay
Slow (3 Hz) 1.66 s
Medium (20 Hz) 250 ms
Fast (200 Hz) 25 ms
Trigger Delay
1 s
