114 U8903A User’s Guide
6 Frequency and Time Domain Analysis
Marker
The Marker menu provides you access to the available
marker functions.
To access the Marker menu, press on the Graph
panel. The first page of the marker menu is shown as
follows.
Figure 6-8 Marker menu
Using the marker functions, you may set the current and
reference markers to be placed on the graph for the selected
channel. The markers can be moved along the graph plot by
rotating the knob on the U8903A front panel.
You also have the option to display the measurement data of
the selected marker(s) in a table as shown in Figure 6- 9.
For more information on the marker functions, refer to the U8903A Audio
Analyzer Instrument Help File.
