26 U8903A User’s Guide
2 Operation and Features

The generator function menu tree for Output Settings,
Frequency, Amplitude, and DC Offset is shown as follows.
Figure 2-4 Generator: Output Settings, Frequency, Amplitude, and DC Offset menu tree
Generator
Output Type
Amplitude
Balanced
Unbalanced
Common
Frequency
DC Offset
Output Settings
Impedance
50 /600 
100 /600 
For Balanced or Common mode output connection,
impedance selection is 100  and 600 .
For Unbalanced output connection, impedance selection
is 50 and 600 .
*
*
*
