Sweep capability
FREQUENCY SWEEP (SINE AND DUAL SINE WAVEFORMS)
Start point 5 Hz to 80 kHz
Stop point 5 Hz to 80 kHz
Amplitude spot value
(Balanced)
0 V to 16 Vrms
Amplitude spot value
(Unbalanced/Common)
0 V to 8 Vrms
FREQUENCY SWEEP (SQUARE WAVEFORM)
Start point 5 Hz to 30 kHz
Stop point 5 Hz to 30 kHz
Amplitude spot value
(Balanced)
0 V to 22.6 Vrms
Amplitude spot value
(Unbalanced/Common)
0 V to 11.3 Vrms
FREQUENCY SWEEP (SMPTE IMD 1:1/4:1/10:1 WAVEFORM)
Start point (Upper frequency) 2 kHz to 60 kHz
Start point (Lower frequency) 40 Hz to 500 Hz
Stop point (Upper frequency) 2 kHz to 60 kHz
Stop point (Lower frequency) 40 Hz to 500 Hz
Amplitude spot value
(Balanced)
0 V to 16 Vrms
Amplitude spot value
(Unbalanced/Common)
0 V to 8 Vrms
FREQUENCY SWEEP (DFD IEC 60118/IEC 60268 WAVEFORM)
Start point (Upper frequency) 3 kHz to 80 kHz
Start point (Center frequency) 3 kHz to 79 kHz
Stop point (Upper frequency) 3 kHz to 80 kHz
Stop point (Center frequency) 3 kHz to 79 kHz
Amplitude spot value
(Balanced)
0 V to 16 Vrms
Amplitude spot value
(Unbalanced/Common)
0 V to 8 Vrms
Difference frequency spot value 80 Hz to 2 kHz
