Operation and Features 2
U8903A User’s Guide 47
Table 2-8 System menu description
Level 1 Level 2 Level 3 Level 4 Description
I/O GPIB Address Enter the GPIB address value
FTP Control Enable
Disable
Enables or disables the FTP control
LAN Settings Configure Mode Automatic
Manual
Select the mode to enter the LAN settings
Save Settings Saves the LAN settings
Reset Settings Resets the LAN settings
Date/Time Edit Enter the date and time
Save Saves the date and time settings
Cancel Cancels the changes made
Brightness Adjust the brightness of the LCD display from
0 to 6
Service Self-Test Complete Test Performs a full instrument self-test
Customized Test Performs a self-test on a particular section of
the U8903A
Diagnostic Front Panel Performs a diagnostic test on the U8903A
front panel. You can verify whether a key is
functional by observing the change of color
for the pressed key.
Display Performs a diagnostic test on the LCD
display. Full color will be displayed to check
for bad pixel.
Secure Erase Eradicates stored data in the U8903A.
Update Application Performs an update of the U8903A
application
DSP Firmware Master
FFT
Card 1
Select the DSP firmware to update consisting
of Master, FFT, and Card 1
Power-Up State Default Sets the U8903A to its default power-on state
Last Settings Sets the U8903A to its previous setting mode
upon power up
