The description for each key on the Mode panel is shown in
the table below.
Generator
Pressing changes the display screen to the
generator screen. On the Generator menu, you can set
various settings for audio signal generation, with waveform
type, frequency, amplitude, DC offset, and output as the
main settings. The generator function menu tree is divided
into three parts as shown in the following pages. The first
section of the menu tree shows the waveform functions
consisting of Sine, Variable Phase, and Dual Sine while the
second section shows the other waveform functions
comprising Noise, DC, Multitone, Square, and Arbitrary. The
third section of the menu tree displays the Output Settings,
Frequency, Amplitude, and DC Offset functions. Use the
softkey on the right side of the LCD display to navigate to
the next menu level.
Table 2-1 Mode panel key description
Item Key Description
1 Generator Selects the generator function
2 Analyzer Selects the analyzer function
3 Frequency Domain Selects the frequency domain analysis
4 Time Domain Selects the time domain analysis
5 Sweep Selects the sweep function
