Agilent Technologies u8903a

Operation and Features 2
U8903A User’s Guide 49
Front Panel LCD Display
The U8903A displays the analyzer view upon power- up, as
shown in the following figure.
Figure 2-18 Power-up display
Measurement results
Measurement status
Softkey menu
Active channel
Function 1
Function 2
Analyzer settings
Channel 2
Status display
LAN status
USB status
