Specifications 8
U8903A User’s Guide 129
DC
Output
Range (Balanced) –22.6 V to 22.6 V
Range (Unbalanced/Common) –11.3 V to 11.3 V
Amplitude accuracy 1.5%
DC OFFSET
Applicable for all waveform types except Variable Phase, DC, and Square
Output level
Range –11.3 V to 11.3 V
Amplitude accuracy 1.5%
OUTPUT CHARACTERISTICS
Connection type
Balanced XLR
Unbalanced BNC
Common mode XLR
Impedance
Balanced 100 , 600
Unbalanced 50 , 600
Output current limit (typical) 50 mA
Maximum output power into
600
Balanced (600 )20 dBm
Unbalanced (600 )14 dBm
Crosstalk
20 Hz to 20 kHz –101 dB (at 23 °C ± 5 °C)
–99 dB (from 0 °C to 55 °C)
20 kHz to 80 kHz –85 dB
