34 U8903A User’s Guide

2 Operation and Features



Level 1 Level 2 Level 3 Description

Units Function 1

Function 2

Hz

dBu

dBV

dBm

dBr

dBg

dB



Select the unit according to the function type

Analyzer

Settings

Coupling AC

Select either AC or DC coupling

Detector RMS

QPK

Peak-to-Peak

Select either RMS, Quasi Peak, or Peak-to-Peak

detection type

Filter None Unselect the filter function

LPF Select either None, 15 kHz, 20 kHz, 30 kHz, or

Custom

HPF Select either None, 22 Hz, 100 Hz, 400 Hz, or

Custom

Weighting Select either None, A-Weighting, CCIR 1k wtd,

CCIR 2k wtd, C-Message, CCITT, or Custom

Input Type Balanced

Unbalanced

Select either Balanced or Unbalanced input

connection

Range Auto

400 mV to 140 V

Select the input range

Table 2-3 Analyzer menu description (continued)
