1-30 Installation/Wiring
Essential Requirements for FCC Compliance
Conditions 1-4 listed below must be satisfied for PowerFlex 400 drives
to meet the requirements of FCC Part 15 Subpart B.
1. Grounding as described in Figure 1.11. Refer to page 1-9 for
additional grounding recommendations.
2. Output power, control (I/O) and signal wiring must be braided,
shielded cable with a coverage of 75% or better, metal conduit or
equivalent attenuation.
3. All shielded cables should terminate with the proper shield
connector.
4. Conditions in Table 1.K
.
Table 1.K PowerFlex 400 – FCC Part 15 Subpart B Compliance
PowerFlex 400 Drive Required Filter Restrict Motor
Cable to (Meters)
Install Drive and
Filter in
Enclosure
kW (HP) Cat. No.
200-240 Volts
2.2 (3.0) 22C-B012N103 22-RF034-CS 10 No
3.7 (5.0) 22C-B017N103 22-RF034-CS 10 No
5.5 (7.5) 22C-B024N103 22-RF034-CS 10 No
7.5 (10) 22C-B033N103 22-RF034-CS 10 No
11 (15) 22C-B049A103 22-RFD070 150 Required
15 (20) 22C-B065A103 22-RFD100 150 Required
18.5 (25) 22C-B075A103 22-RFD100 150 Required
22 (30) 22C-B090A103 22-RFD150 150 Required
30 (40) 22C-B120A103 22-RFD150 150 No
37 (50) 22C-B145A103 22-RFD180 150 No
380-480 Volts
2.2 (3.0) 22C-D6P0N103 22-RF018-CS 10 No
4.0 (5.0) 22C-D010N103 22-RF018-CS 10 No
5.5 (7.5) 22C-D012N103 22-RF018-CS 10 No
7.5 (10) 22C-D017N103 22-RF018-CS 10 No
11 (15) 22C-D022N103 22-RF026-CS 10 No
15 (20) 22C-D030N103 22-RFD036 100 No
18.5 (25) 22C-D038A103 22-RFD050 150 No
22 (30) 22C-D045A103 22-RFD050 150 No
30 (40) 22C-D060A103 22-RFD070 50 No
37 (50) 22C-D072A103 22-RFD100 50 No
45 (60) 22C-D088A103 22-RFD100 50 No
55 (75) 22C-D105A103 22-RFD150 150 No
75 (100) 22C-D142A103 22-RFD180 50 No
90 (125) 22C-D170A103 Consult Factory
110 (150) 22C-D208A103 Consult Factory
