Allen-Bradley Stratix 5700 User Manual

Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 17
Chapter 1
About the Switches
Stratix® managed switches provide a secure switching infrastructure for harsh
environments. You can connect the switches to network devices such as servers,
routers, and other switches. In industrial environments, you can connect
Ethernet-enabled industrial communication devices, including programmable
logic controllers (PLCs), human machine interfaces (HMIs), drives, sensors,
and I/O.
Table 1 on page 18 describes the Stratix switch families.
Topic Page
EtherNet/IP CIP Interface 19
Lite Versus Full Firmware Features (Stratix 5700 Switches) 20
Software Features 21
Hardware Features 22
Memory Allocation 25

Allen-Bradley Stratix 5700 Specifications

General

Model	Stratix 5700
Port Types	RJ45, SFP
Mounting	DIN Rail or Panel Mount
Dimensions	Varies by model
Weight	Varies by model
Management	Web-based, SNMP, Command Line
Redundancy	Device Level Ring, STP, RSTP
Operating Temperature	-40°C to 70°C
Power Supply	Dual DC inputs
Input Voltage	24 VDC or 100-240 VAC
Protocols	EtherNet/IP, DLR
Security Features	SSH, HTTPS, RADIUS, TACACS+
