Page #22 background image
22 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Chapter 1 About the Switches
Hardware Features
See the following for a description of hardware features:
For Stratix 5400, Stratix 5700, ArmorStratix 5700, and Stratix 8000/
8300 switches, see
Table 3 on page 23.
For Stratix 5410 switches, see
Table 4 on page 24.
For supported SFP modules, see the Stratix Ethernet Device
Specifications Technical Data, publication
1783-TD001.
Network Address Translation (NAT) All Stratix 5400 switches
All Stratix 5410 switches
Stratix 5700 switches: 1783-BMS10CGN, 1783-BMS20CGN, 1783-BMS12T4E2CGNK
ArmorStratix 5700 switches: 1783-ZMS4T4E2TGN, 1783-ZMS8T8E2TGN
••
Network Time Protocol Stratix 5400 switches
Stratix 5410 switches
Stratix 5700 switches
ArmorStratix 5700 switches
Stratix 8000 switches
Stratix 8300 switches
Parallel Redundancy Protocol (PRP) Stratix 5400 switches
Stratix 5410 switches
Port Mirroring All
Port Security All
••
Port Thresholds All
••
Power over Ethernet (PoE) Stratix 5400 switches: 1783-HMS4T4E4CGN, 1783-HMS4S8E4CGN, 1783-HMS4EG8CGN,
1783-HMS8TG8EG4CGN, 1783-HMS4SG8EG4CGN,1783-HMS4EG8CGR,
1783-HMS8TG8EG4CGR, 1783-HMS4SG8EG4CGR
All Stratix 5410 switches
Stratix 5700 switches: 1783-BMS12T4E2CGNK, 1783-BMS12T4E2CGP, 1783-BMS12T4E2CGL
ArmorStratix 5700 switches: 1783-ZMS4T4E2TGP, 1783-ZMS8T8E2TGP, 1783-ZMS4T4E2TGN,
1783-ZMS8T8E2TGN
Stratix 8000 and 8300 expansion modules: 1783-MX04E, 1783-MX04T04E
••
Resilient Ethernet Protocol (REP) All
Static and Connected Routing All
Open Shortest Path First (OSPF)
Gateway Routing Protocol
Stratix 5400 switches with Layer 3 firmware
Stratix 5410 switches with Layer 3 firmware
Stratix 8300 base units
Simple Network Management Protocol
(SNMP)
All
Smartports All
••
Spanning Tree Protocol (STP) All
••
Virtual Local Area Networks (VLANs) All
••
Table 2 - Software Features (continued)
Feature Switches Device Manager Logix Designer
