Allen-Bradley Stratix 5700 User Manual

Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 505
Port Numbering Appendix C
Stratix 5700 Port Numbering
The port ID consists of the following:
• Port type (Gigabit Ethernet for Gigabit ports and Fast Ethernet for
10/100 Mbps ports)
• Unit number (always 1)
• Port number (1…2 for Gigabit ports, 1…18 for all others, depending on
the catalog number)
Gigabit Ethernet is abbreviated as Gi and Fast Ethernet as Fa.
Table 166 - Stratix 5700 Port Numbering
Cat. No. Description Port Numbering on Switch Labels Port Numbering in config.text File
1783-BMS4S2SGL 6-port (4 SFP slots; 2 SFP Gigabit slots) managed switch;
lite firmware
1
2
3
4
5
6
Fa1/1
Fa1/2
Fa1/3
Fa1/4
Fa1/5
Fa1/6
1783-BMS4S2SGA 6-port (4 SFP slots; 2 SFP Gigabit slots) managed switch;
full firmware
1
2
3
4
5
6
Fa1/1
Fa1/2
Fa1/3
Fa1/4
Fa1/5
Fa1/6
1783-BMS06SL 6-port (4 Ethernet ports; 2 SFP slots) managed switch; lite firmware 1
2
3
4
5
6
Fa1/1
Fa1/2
Fa1/3
Fa1/4
Fa1/5
Fa1/6
1783-BMS06SA 6-port (4 Ethernet ports; 2 SFP slots) managed switch; full firmware 1
2
3
4
5
6
Fa1/1
Fa1/2
Fa1/3
Fa1/4
Fa1/5
Fa1/6
1783-BMS06TL 6-port (6 Ethernet ports) managed switch; lite firmware 1
2
3
4
5
6
Fa1/1
Fa1/2
Fa1/3
Fa1/4
Fa1/5
Fa1/6
1783-BMS06TA 6-port (6 Ethernet ports) managed switch; full firmware 1
2
3
4
5
6
Fa1/1
Fa1/2
Fa1/3
Fa1/4
Fa1/5
Fa1/6
1783-BMS06SGL 6-port (4 Ethernet ports; 2 SFP Gigabit slots) managed switch;
lite firmware
1
2
3
4
1
2
Fa1/1
Fa1/2
Fa1/3
Fa1/4
Gi1/1
Gi1/2

Allen-Bradley Stratix 5700 Specifications

General

Model	Stratix 5700
Port Types	RJ45, SFP
Mounting	DIN Rail or Panel Mount
Dimensions	Varies by model
Weight	Varies by model
Management	Web-based, SNMP, Command Line
Redundancy	Device Level Ring, STP, RSTP
Operating Temperature	-40°C to 70°C
Power Supply	Dual DC inputs
Input Voltage	24 VDC or 100-240 VAC
Protocols	EtherNet/IP, DLR
Security Features	SSH, HTTPS, RADIUS, TACACS+
