Allen-Bradley Stratix 5700 User Manual

512 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Appendix C Port Numbering
ArmorStratix 5700
Port Numbering
The port ID consists of the following:
• Port type (Gigabit Ethernet for Gigabit ports and Fast Ethernet for
10/100 Mbps ports)
• Unit number (always 1)
• Port number (1…2 for Gigabit ports, 1…18 for all others, depending on
the catalog number)
Gigabit Ethernet is abbreviated as Gi and Fast Ethernet as Fa.
Table 167 - ArmorStratix 5700 Port Numbering
Cat. No. Description Port Numbering on Switch Labels Port Numbering in config.text File
1783-ZMS8TA 8-port (8 Ethernet ports) managed switch; full firmware 1
2
3
4
5
6
7
8
Fa1/1
Fa1/2
Fa1/3
Fa1/4
Fa1/5
Fa1/6
Fa1/7
Fa1/8
1783-ZMS4T4E2TGP 10-port (2 Gigabit ports; 4 Ethernet ports; 4 PoE/PoE+ ports)
managed switch; full firmware; PTP
GE-1
GE-2
1
2
3
4
5
6
7
8
Gi1/1
Gi1/2
Fa1/1
Fa1/2
Fa1/3
Fa1/4
Fa1/5
Fa1/6
Fa1/7
Fa1/8
1783-ZMS4T4E2TGN 10-port (2 Gigabit ports; 4 Ethernet ports; 4 PoE/PoE+ ports)
managed switch; full firmware; PTP; NAT
GE-1
GE-2
1
2
3
4
5
6
7
8
Gi1/1
Gi1/2
Fa1/1
Fa1/2
Fa1/3
Fa1/4
Fa1/5
Fa1/6
Fa1/7
Fa1/8
1783-ZMS16TA 16-port (16 Ethernet ports) managed switch; full firmware 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Fa1/1
Fa1/2
Fa1/3
Fa1/4
Fa1/5
Fa1/6
Fa1/7
Fa1/8
Fa1/9
Fa1/10
Fa1/11
Fa1/12
Fa1/13
Fa1/14
Fa1/15
Fa1/16

Allen-Bradley Stratix 5700 Specifications

General

Model	Stratix 5700
Port Types	RJ45, SFP
Mounting	DIN Rail or Panel Mount
Dimensions	Varies by model
Weight	Varies by model
Management	Web-based, SNMP, Command Line
Redundancy	Device Level Ring, STP, RSTP
Operating Temperature	-40°C to 70°C
Power Supply	Dual DC inputs
Input Voltage	24 VDC or 100-240 VAC
Protocols	EtherNet/IP, DLR
Security Features	SSH, HTTPS, RADIUS, TACACS+
