Allen-Bradley Stratix 5700 User Manual

402 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Chapter 8 Monitor the Switch
Public-to-Private Translation Diagnostics
From the Public to Private Translations dialog box for an instance, you can
view a list of IP addresses that have been changed by NAT within the last 90
seconds.
Table 112 - Public-to-Private Translation Diagnostics
Field Description
Public Displays the unique IP address on the public subnet that represents the corresponding IP address on the private
subnet.
Private Displays the IP address on the private subnet that was changed to a unique IP address on the public subnet.
Subnet Indicates whether the translation is part of a Subnet entry type.
Number of Packets Displays the number of packets that contain the translation.

Allen-Bradley Stratix 5700 Specifications

General

Model	Stratix 5700
Port Types	RJ45, SFP
Mounting	DIN Rail or Panel Mount
Dimensions	Varies by model
Weight	Varies by model
Management	Web-based, SNMP, Command Line
Redundancy	Device Level Ring, STP, RSTP
Operating Temperature	-40°C to 70°C
Power Supply	Dual DC inputs
Input Voltage	24 VDC or 100-240 VAC
Protocols	EtherNet/IP, DLR
Security Features	SSH, HTTPS, RADIUS, TACACS+
