Allen-Bradley Stratix 5700 User Manual

Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 491
Port Assignments for CIP Data Appendix B
Stratix 5700
Port Assignments
Table 162 - 6- and 10-port Switches
Bit 1783-BMS4S2SGL, 1783-BMS4S2SGA,
1783-BMS06SL, 1783-BMS06SA,
1783-BMS06TL, 1783-BMS06TA,
1783-BMS06SGL, 1783-BMS06SGA
1783-BMS06TGL,
1783-BMS06TGA
1783-BMS10CL,
1783-BMS10CA
1783-BMS10CGL, 1783-BMS10CGA,
1783-BMS10CGP, 1783-BMS10CGN
0 Any/All ports Any/All ports Any/All ports Any/All ports
1 Fa1/1 Fa/1 Fa1/1 Fa1/1
2 Fa1/2 Fa1/2 Fa1/2 Fa1/2
3 Fa1/3 Fa1/3 Fa1/3 Fa1/3
4 Fa1/4 Fa1/4 Fa1/4 Fa1/4
5 Fa1/5 Gi1/1 Fa1/5 Fa1/5
6 Fa1/6 Gi1/2 Fa1/6 Fa1/6
7 Fa1/7 Fa1/7
8 Fa1/8 Fa1/8
9 Fa1/9 Gi1/1
10 Fa1/10 Gi1/2
27 SVI1 SVI1 SVI1 SVI1
Table 163 - 18- and 20-port Switches
Bit 1783-BMS12T4E2CGL, 1783-BMS12T4E2CGP,
1783-BMS12T4E2CGNK
1783-BMS20CL, 1783-BMS20CA 1783-BMS20CGL, 1783-BMS20CGN,
1783-BMS20CGP, 1783-BMS20CGPK
0 Any/All ports Any/All ports Any/All ports
1 Fa1/1 Fa1/1 Fa1/1
2 Fa1/2 Fa1/2 Fa1/2
3 Fa1/3 Fa1/3 Fa1/3
4 Fa1/4 Fa1/4 Fa1/4
5 Fa1/5 Fa1/5 Fa1/5
6 Fa1/6 Fa1/6 Fa1/6
7 Fa1/7 Fa1/7 Fa1/7
8 Fa1/8 Fa1/8 Fa1/8
9 Fa1/9 Fa1/9 Fa1/9
10 Fa1/10 Fa1/10 Fa1/10
11 Fa1/11 Fa1/11 Fa1/11
12 Fa1/12 Fa1/12 Fa1/12
13 Fa1/13 Fa1/13 Fa1/13
14 Fa1/14 Fa1/14 Fa1/14
15 Fa1/15 Fa1/15 Fa1/15
16 Gi1/1 Fa1/16 Fa1/16
17 Gi1/2 Fa1/17 Fa1/17
18 Gi1/3 Fa1/18 Fa1/18

Allen-Bradley Stratix 5700 Specifications

General

Model	Stratix 5700
Port Types	RJ45, SFP
Mounting	DIN Rail or Panel Mount
Dimensions	Varies by model
Weight	Varies by model
Management	Web-based, SNMP, Command Line
Redundancy	Device Level Ring, STP, RSTP
Operating Temperature	-40°C to 70°C
Power Supply	Dual DC inputs
Input Voltage	24 VDC or 100-240 VAC
Protocols	EtherNet/IP, DLR
Security Features	SSH, HTTPS, RADIUS, TACACS+
