Allen-Bradley Stratix 5700 - 16-Port Switches

462 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Appendix A Data Types
16-port Switches
Catalog number 1783-ZMS16TA
Table 146 - Output Data Type (10-port switches)
AB:STRATIX_5700_10PORT_MANAGED:O:0
Member Name Type Default Display
Style
Valid Values
AllPortsDisabled BOOL Decimal DisablePort:0
PortFa1_1Disable BOOL Decimal DisablePort:1
PortFa1_2Disable BOOL Decimal DisablePort:2
PortFa1_3Disable BOOL Decimal DisablePort:3
PortFa1_4Disable BOOL Decimal DisablePort:4
PortFa1_5Disable BOOL Decimal DisablePort:5
PortFa1_6Disable BOOL Decimal DisablePort:6
PortFa1_7Disable BOOL Decimal DisablePort:7
PortFa1_8Disable BOOL Decimal DisablePort:8
PortFa1_9Disable BOOL Decimal DisablePort:9
PortFa1_10Disable BOOL Decimal DisablePort:10
Table 147 - Input Data Type (16-port switches)
AB:STRATIX_5700_16PORT_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
Fault DINT Binary
AnyPortConnected BOOL Decimal LinkStatus:0
PortFa1_1Connected BOOL Decimal LinkStatus:1
PortFa1_2Connected BOOL Decimal LinkStatus:2
PortFa1_3Connected BOOL Decimal LinkStatus:3
PortFa1_4Connected BOOL Decimal LinkStatus:4
PortFa1_5Connected BOOL Decimal LinkStatus:5
PortFa1_6Connected BOOL Decimal LinkStatus:6
PortFa1_7Connected BOOL Decimal LinkStatus:7
PortFa1_8Connected BOOL Decimal LinkStatus:8
PortFa1_9Connected BOOL Decimal LinkStatus:9
PortFa1_10Connected BOOL Decimal LinkStatus:10
PortFa1_11Connected BOOL Decimal LinkStatus:11
PortFa1_12Connected BOOL Decimal LinkStatus:12
PortFa1_13Connected BOOL Decimal LinkStatus:13
PortFa1_14Connected BOOL Decimal LinkStatus:14
PortFa1_15Connected BOOL Decimal LinkStatus:15
PortFa1_16Connected BOOL Decimal LinkStatus:16
