Allen-Bradley Stratix 5700 - 20-Port Gb Switches

Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 465
Data Types Appendix A
20-port Gb Switches
Catalog numbers 1783-BMS20CGL, 1783-BMS20CGN, 1783-BMS20CGP,
1783-BMS20CGPK
Table 149 - Input Data Type (20-port Gb switches)
AB:STRATIX_5700_20PORT_GB_MANAGED:I:0
Member Name Type Default
Display Style
Valid Values
Fault DINT Binary
AnyPortConnected BOOL Decimal LinkStatus:0
PortFa1_1Connected BOOL Decimal LinkStatus:1
PortFa1_2Connected BOOL Decimal LinkStatus:2
PortFa1_3Connected BOOL Decimal LinkStatus:3
PortFa1_4Connected BOOL Decimal LinkStatus:4
PortFa1_5Connected BOOL Decimal LinkStatus:5
PortFa1_6Connected BOOL Decimal LinkStatus:6
PortFa1_7Connected BOOL Decimal LinkStatus:7
PortFa1_8Connected BOOL Decimal LinkStatus:8
PortFa1_9Connected BOOL Decimal LinkStatus:9
PortFa1_10Connected BOOL Decimal LinkStatus:10
PortFa1_11Connected BOOL Decimal LinkStatus:11
PortFa1_12Connected BOOL Decimal LinkStatus:12
PortFa1_13Connected BOOL Decimal LinkStatus:13
PortFa1_14Connected BOOL Decimal LinkStatus:14
PortFa1_15Connected BOOL Decimal LinkStatus:15
PortFa1_16Connected BOOL Decimal LinkStatus:16
PortFa1_17Connected BOOL Decimal LinkStatus:17
PortFa1_18Connected BOOL Decimal LinkStatus:18
PortGi1_1Connected BOOL Decimal LinkStatus:19
PortGi1_2Connected BOOL Decimal LinkStatus:20
AnyPortUnauthorizedDevice BOOL Decimal UnauthorizedDevice:0
PortFa1_1UnauthorizedDevice BOOL Decimal UnauthorizedDevice:1
PortFa1_2UnauthorizedDevice BOOL Decimal UnauthorizedDevice:2
PortFa1_3UnauthorizedDevice BOOL Decimal UnauthorizedDevice:3
PortFa1_4UnauthorizedDevice BOOL Decimal UnauthorizedDevice:4
PortFa1_5UnauthorizedDevice BOOL Decimal UnauthorizedDevice:5
PortFa1_6UnauthorizedDevice BOOL Decimal UnauthorizedDevice:6
PortFa1_7UnauthorizedDevice BOOL Decimal UnauthorizedDevice:7
PortFa1_8UnauthorizedDevice BOOL Decimal UnauthorizedDevice:8
PortFa1_9UnauthorizedDevice BOOL Decimal UnauthorizedDevice:9
PortFa1_10UnauthorizedDevice BOOL Decimal UnauthorizedDevice:10
PortFa1_11UnauthorizedDevice BOOL Decimal UnauthorizedDevice:11
