Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 369

Configure Switch Features Chapter 7

Configure VLANs via the Logix Designer Application

VLAN configuration via the Logix Designer application is available for only

Stratix 5400, Stratix 5410, Stratix 5700, and ArmorStratix 5700 switches.

In the navigation pane, click Smarports & VLANs.

In the VLAN Configuration area, you can add, edit, and delete VLANs.

Figure 51 - VLAN Configuration for Stratix 5400, Stratix 5410, Stratix 5700, and ArmorStratix 5700 Switches

To assign ports to VLANs, see Assign Smartports and VLANs via the Logix

Designer Application on page 358.
